Mount Garibaldi

Mount Garibaldi as seen from Squamish

Mount Garibaldi is a potentially active stratovolcano in the Squamish-Lillooet Regional District of British Columbia, Template:Unit km north of Vancouver, Canada. Located in the southernmost Coast Mountains, it is one of the most recognized peaks in the South Coast region, as well as British Columbia's best known volcano. It lies within the Garibaldi Ranges of the Pacific Ranges.

This heavily erected dome complex occupies the southeast corner of Garibaldi Provincial Park overlooking the town of Squamish. It is the only major Pleistocene age volcano in North America known to have formed upon a glacier. Although part of the Garibaldi Volcanic Belt within the Cascade Volcanic Arc, it is not considered part of the Cascade Range.

Human historyEdit

Indigenous people Edit

To Sḵwxwú7mesh, the local indigenous people of this territory, the mountain is called Nch'kay. In their language it means "Dirty Place" or "Grimy One". This name of the mountain refers to the water in the Cheekye River with its muddy water. This mountain, like other located in the area, are considered sacred for it plays an important part of their history. In their oral history, they passed down a story of the flood covering the land. During this time, only two mountains peaked over the water, and this mountain was one of them. It was here that the remaining survivors of the flood latched their canoes to the peak and waited for the waters to subside. The mountain also serves as weather indicator to the people, as when clouds cover the face of the mountain, it signals the coming of rain or snow. Cultural ceremonial use, hunting, trapping and plant gathering occur around the Mount Garibaldi area, but the most important resources was a lithic material called obsidian. Obsidian is a black slate martial used to make knives, chisels, adze’s, and other sharp tools in pre-contact times. This material appears in sites dated 10,000 years ago up to “protohistoric time periods”. The source for this material is found in upper parts of the mountain area in higher elevations that surround the mountain range.

Later historyEdit

British Explorer Captain George Vancouver reached Howe Sound in June 1792 and became the first European to see the mountain. During this time George Vancouver met and traded with the local natives in the area.

Giuseppe Garibaldi (1866)

Mount Garibaldi was named after Giuseppe Garibaldi in 1860

In 1860, while carrying out a survey of Howe Sound on board the Royal Navy survey ship HMS Plumper, Captain George Henry Richards was impressed by a gigantic mountain dominating the view to the northeast. Captain Richards, and his officers, re-named the mountain after the Italian military and political leader Giuseppe Garibaldi, who that year had succeeded in unifying Italy by patriating Sicily and Naples. In August 1907, the Vancouver mountaineers A. Dalton, W. Dalton, A. King, T. Pattison, J.J. Trorey, and G. Warren reached the summit of Mount Garibaldi. The views from the peak inspired the establishment of summer climbing camps at Garibaldi Lake. This early interest led to the creation in 1920 of a park reserve.

In 1927, Garibaldi was made into a large wilderness park called Garibaldi Provincial Park. Named after Mount Garibaldi, this 194,650 hectare park was established to protect the rich geological history, diverse vegetation, iridescent waters, abundant wildlife, and rugged mountains, many of which are capped by glaciers.

When skiing caught on in the 1940s, Vancouver skiers began to search the glaciers and rugged mountains within the park. Early skiing was limited to the more easily reached area around Garibaldi Lake. In the winter of 1944, a club group completed the first possible ski of Mount Garibaldi. The famous mountaineers Don and Phyllis Munday completed lots of tracks additionally. In the 1944-45 Canadian Alpine Journal, the Mundays reported a ski attempt on Mount Garibaldi with Phil Brook, who was a friend of the Mundays. They skied on Sphinx Glacier and scrabbled Panorama Ridge just north of Garibaldi Lake during the same trip. Most importantly, during this period a road was built on Paul Ridge near the small community of Squamish at the north end of Howe Sound, therefore granted better vehicle approach to the highlands near Mount Garibaldi. With easier access Vancouver skiers spent even more time on the glaciers of Mount Garibaldi. The result of this was the formation in the 1940s of the Garibaldi Névé Traverse, an overnight adventure that (weather permitting) can include a fine descent of Mount Garibaldi.

Subsidiary peaksEdit

MtGaribaldi-NorthFace-TheTable

The north face of Mount Garibaldi rises above The Table and Garibaldi Lake

The broad top of Mount Garibaldi contains three named peaks. The highest peak is named as the mountain itself, reaching Template:Unit m above sea level. The seconed highest peak is the sharp pyramid of Atwell Peak at the southern edge of the summit plateau, which reaches a height of Template:Unit m and lies on the southwest end of Garibaldi Provincial Park. This peak is named after Atwell Duncan Francis Joseph King, leader of the first ascent of Mount Garibaldi in 1907. The lowest of the three is the rounded Dalton Dome, Template:Unit m high, west of the highest summit. This peak is named after Arthur Tinniswood Dalton, one of the guides of the 1907 ascent.

A feature on the north side of the mountain, known as The Tent, reaches Template:Unit m and lies in Garibaldi Provincial Park. Another minor summit on the south side of the mountain, Template:Unit m high, is known as Diamond Head (sometimes Little Diamond Head) for its resemblance to Diamond Head in Hawaii. Diamond Head was the site of a ski proposal and small lodge, now derelict. On the northwest side of Mount Garibaldi, Brohm Ridge lies outside the western boundary of Garibaldi Provincial Park. The Sharkfin sticks up out of the Warren Glacier on the northeast side of the mountain with a height of Template:Unit m, just northeast of Squamish. Columnar Peak rises on the south side of the mountain with a height of Template:Unit m, just southwest of Mamquam Lake at southwest end of Garibaldi Provincial Park. Two pinnacles of volcanic rock Template:Unit km south of Mount Garibaldi's summit, which attain heights of Template:Unit m and Template:Unit m, have been known as The Gargoyles since 1978.

Glaciers and icefieldsEdit

Two pocket glaciers lie right below the east side of Atwell Peak, the Diamond Glacier to the southeast and the upper Bishop Glacier to the northeast. Straight north of Atwell toward Mount Garibaldi lies a small, high-elevation ice cap called the Cheekye Glacier, which is associated with Cheekye River.

A large icefield lies on the eastern and northern flanks of Mount Garibaldi called the Garibaldi Névé. Its drainage is to the east into the Pitt River, to the southwest into Garibaldi Lake. It has an area of 35 km2 and is an area of substantial snowfall with more than Template:Unit m in many winters. The Garibaldi Névé is usually accessed from the south through the Bishop Glacier or from the north through the Sentinel Glacier.

Climbing and recreationEdit

Mount Garibaldi3

Mount Garibaldi and The Table as seen from Black Tusk

Mountain climbing on Mount Garibaldi is fairly difficult; it is fairly steep-sided and involves climbing very loose rotten lava and volcanic ash. Fortunately, Mount Garibaldi has large areas of massive glaciation and extensive snowfields. The eastern and northern flanks of the mountain are smothered by the Garibaldi Névé where the finest climbing opportunities exist, making the easiest route a glacial travel or snow climb. Routes keep mostly to the alpine glaciers and snow slopes, which are abundant in winter and spring, but eventually melt in late spring and commonly vanish after June or July of most years. After the snow and ice melts, fissures and fractures can pose difficulty and danger, and avalanches from higher peaks of the mountain are a hazard. For this reason, early season, cold-weather ascents are recommended for most routes up Garibaldi.

Hiking, photography, and camping are popular in the Garibaldi area. Hiking trails, including the Garibaldi Lake Trail, a Template:Unit km circumnavigation of the peak provide access to the backcountry. Mount Garibaldi is also popular for winter sports, including cross-country skiing. In summer, visitors pass through meadows of wildflowers, on trails emanating from Garibaldi Provincial Park.

GeologyEdit

Atwell Peak 2

Atwell Peak

Mount Garibaldi lies within the Coast Plutonic Complex, which is the single largest contiguous granite outcropping in North America. The intrusive and metamorphic rocks extend approximately Template:Unit km along the coast of British Columbia, the Alaska Panhandle and southwestern Yukon. This is a remnant of a once vast volcanic arc called the Coast Range Arc that formed as a result of subduction of the Farallon and Kula Plates during the Jurassic-to-Eocene periods. In contrast, Garibaldi, Meager, Cayley and Silverthrone areas are of recent volcanic origin.

Mount Garibaldi is one of the few Cascade volcanoes that is made exclusively of dacite (Glacier Peak is the other). The mountain has a unique asymmetrical shape because its main cone was constructed atop part of a large glacier system associated with the Cordilleran Ice Sheet that has since melted away. Unlike many of the other Cascade volcanoes to the south, Garibaldi does not dominate the surrounding landscape, which consists of many high, rugged peaks. Many residents of Vancouver are therefore not aware that there is a volcano closer to the city than the more easily visible Mount Baker in Washington State.

OriginsEdit

File:Garibaldi Volcanic Belt-en.svg

Mount Garibaldi began erupting about 2 years ago and has grown steadily since then. Like all of the Cascade volcanoes, Mount Garibaldi has its origins in the Cascadia subduction zone—a long convergent plate boundary that stretches from mid-Vancouver Island to Northern California. The subduction zone separates the Juan de Fuca, Explorer, Gorda and North American Plates. Here, the oceanic crust of the Pacific Ocean sinks beneath North America at a rate of Template:Convert/mm per year. Hot magma upwelling above the descending oceanic plate creates volcanoes, and each individual volcano erupts for a few million years.

The subduction zone has existed for at least 37 million years, and has created a line of volcanoes called the Cascade Volcanic Arc which stretches over Template:Unit km along the subduction zone. Several volcanoes in the arc are potentially active. Lassen Peak in California, which last erupted in 1917, is the southernmost historically active volcano in the arc, while Mount Meager, just north of Mount Garibaldi, which erupted about 2,350 years ago, is generally considered the northernmost. A few isolated volcanic centers northwest of Mount Meager, such as the Silverthrone Caldera, which is a circular Template:Unit km wide, deeply dissected caldera complex, are considered by some geologists to be the northernmost member of the arc.

StructureEdit

File:Mount Garibaldi topographic map-en.svg

Mount Garibaldi is the largest volcano in southernmost British Columbia. Like other stratovolcanoes, it is composed of many layers of hardened lava, tephra, and volcanic ash. Eruptions are explosive in nature, and the most common form is the Peléan style, which involves viscous magma, glowing avalanches of hot volcanic ash and pyroclastic flows. The source magma of this rock is classified as acidic, having high to intermediate levels of silica (as in rhyolite, dacite, or andesite). The tephra deposits have lower volume and range than the corresponding Plinian and Vulcanian eruptions.

Mount Garibaldi is known both for the very high quality exposures of its internal structure and for its conspicuous topographic anomalies, which can be attributed to the growth of the mountain onto a large glacier system and the subsequent collapse of the flanks of the volcano with the melting of the ice. The western flanks of the mountain expose basement rocks, sheared and altered quartz diorite, carved by streams and glaciers into a rugged topography with relief up to Template:Unit m. Valleys in this jagged surface have been filled with 0.52 to 0.22 million year old dacite and andesite flows, tuff breccias, and domes, precursors of the activity at Mount Garibaldi. About Template:Convert/cumi of material remains in the volcano. In modern times, the apron of material around the volcano's main vent extends at least Template:Unit km from its source in places that were covered by ice. In other areas its extent is less and its slope is steeper.

Stratovolcanoes are a common feature of subduction zones. The magma that forms them arises when water, which is trapped both in hydrated minerals and in the porous basalt rock of the upper oceanic crust, is released into mantle rock of the asthenosphere above the sinking oceanic slab. The release of water from hydrated minerals is termed "dewatering", and occurs at specific pressure/temperature conditions for specific minerals as the plate subducts to lower depths. The water freed from the subducting slab lowers the melting point of the overlying mantle rock, which then undergoes partial melting and rises due to its density relative to the surrounding mantle rock, and pools temporarily at the base of the lithosphere. The magma then rises through the crust, incorporating silica rich crustal rock, leading to a final intermediate composition. When the magma nears the surface it pools in a magma chamber under the volcano. The relatively low pressure of the magma allows water and other volatiles (CO2, S2-, Cl-) dissolved in the magma to begin to come out of solution, much like when a bottle of carbonated water is opened. Once a critical volume of magma and gas accumulates, the obstacle provided by the volcanic cone is overcome, leading to a sudden explosive eruption.

Ancestral stages of eruptive activityEdit

File:Mount Garibaldi outline.jpg

The mountain grew in three phases. Garibaldi's first phase resulted in the creation of a broad composite cone made of dacite and breccia that has been potassium-argon dated to 250,000 years old. Parts of this "proto-Garibaldi" or ancestral volcano are exposed on Garibaldi's lower northern and eastern flanks and on the upper Template:Unit m of Brohm Ridge. Around where Columnar Peak and possibly Glacier Pikes are now located, a series of coalescing dacite lava domes were constructed. During the ensuing long period of dormancy, the Cheekye River cut a deep valley into the cone's western flank that was later filled with a glacier.

After reaching its maximum extent the Cheekye Glacier along with part of the area's ice sheet were covered with volcanic ash and fragmented debris from Garibaldi. This period of growth began with the eruption of the Atwell Peak plug dome from a ridge surrounded by the several thousand foot ice sheet. As the plug dome rose, massive sheets of broken lava crumbled as talus down its sides. Numerous Peléan pyroclastic flows (consisting of a super-heated mix of gas, ash, and pumice) accompanied these cooler avalanches, forming a fragmental cone Template:Convert/km3 in volume and an overall slope of 12 to 15 degrees. (Erosion has since steepened this slope.) Some of the glacial ice was melted by the eruptions, forming a small lake against Brohm Ridge's southern arm. The volcanic sandstones seen today atop Brohm Ridge were created by ash settling in this lake.

File:Elfin Lakes, Opal Cone.jpg

Glacial overlap was most significant on the west and somewhat to the south. Subsequent melting of the ice sheet and its component glaciers initiated a series of avalanches and mudflows on Garibaldi's western flank that moved nearly half of the original cone's volume into the Squamish Valley. This series of debris flows carried Template:Convert/km3 of the mountain into the Squamish Valley where it covers Template:Convert/sqmi to a thickness of about Template:Convert/ft. Gaps left by melting ice caused minor to moderate cone distortion where the ice sheet was thin and major distortion where it was thick. The ice was thickest in and thus cone distortion was greatest over the buried Cheekye valley.

Soon before or after the buried ice had melted away, dacite lava quietly erupted from Opal Cone southeast of the Atwell Peak plug dome 10,700 to 9,300 years ago[1] and flowed Template:Unit km down Ring Creek on Garibaldi's southern and southwestern flanks without encountering any residual glacial ice. One of the lava flows traveled down a 30% to 35% grade over the landslide scar on the western flank. About Template:Convert/cumi of dacite erupted in Garibaldi's third period of activity.[2] This lava forms a thin layer of solid rock on the southern and western sides of the volcano and contains well-defined lava flow margin levees. The Ring Creek lava flow is very unusual because lengthy lava flows are usually attained by fluid basalt flows, except the Ring Creek flow is dacite.

Current activityEdit

File:The Table.jpg

Mount Garibaldi is one of the eleven Canadian volcanoes most strongly associated with recent seismic activity; the others are Castle Rock, Mount Edziza, Mount Cayley, Hoodoo Mountain, Lava Fork, Crow Lagoon, Silverthrone Caldera, Mount Meager, Wells Gray-Clearwater Volcanic Field and Nazko Cone. The mountain is informally described as "dormant" ("asleep") because the mountain has not erupted in historic times, nor does it display fumarolic activity like nearby Mount Baker. However, seismic data suggests that these volcanoes still contain living magma plumbing systems, indicating possible future eruptive activity. Although the available data does not allow a clear conclusion, these observations are further indications that some of Canada's volcanoes are potentially active, and that their associated hazards may be significant. The seismic activity correlates both with some of Canada's most youthful volcanoes, and with long-lived volcanic centers with a history of significant explosive behavior, such as Mount Garibaldi. No hot springs are known in the Garibaldi area like those found at Mount Meager and Mount Cayley, the other major volcanic complexes in the Garibaldi belt, although there are hints of anomalously high local heat flow in Table Meadows and elsewhere.

Volcanic hazardsEdit

File:Squamish valley.jpg

Volcanic eruptions in Canada rarely cause fatalities because of there remoteness and low level of activity. The only known fatality due to volcanic activity in Canada occurred at the Tseax Cone in 1775, when a Template:Unit km long basaltic lava flow traveled down the Tseax and Nass Rivers, destroying a Nisga'a village and killing approximately 2,000 people by volcanic gases. Many towns and cities near Mount Garibaldi are home to well over half of British Columbia's human population, and there is a likelihood that future eruptions will cause damage to populated areas, making Mount Garibaldi and other Garibaldi belt volcanoes a major hazard. There are significant hazards from almost all Canadian volcanoes that require hazard maps and emergency plains. Volcanoes which exhibit significant seismic activity, such as Mount Garibaldi, appear to be most likely to erupt. A significant eruption of any of the Garibaldi belt volcanoes would significantly impact Highway 99 and communities like Pemberton, Whistler and Squamish, and possibly Vancouver.

Explosive eruptionsEdit


Explosive eruptions from Mount Garibaldi would pose a severe threat to the nearby communities of Whistler and Squamish. Although no Plinian eruptions have been identified in Garibaldi's eruptive history, even Peléan eruptions could create large amounts of ash that could significantly affect these local communities. Ash columns may rise to several hundred meters above the volcano, and due to its close proximity to Vancouver this could pose a threat for air traffic. Melting of leftover glacial ice covering the Mount Garibaldi area may cause floods, lahars, or debris flows that could possibly threaten small communities such as Brackendale. Highway 99 is already plagued by landslides and debris flows from the steep rugged Coast Mountains. An eruption creating floods could demolish sections of the highway. Flooding and debris flows could also have severe issues for the salmon fishery on the Squamish, Cheakamus, and Mamquam rivers. In addition, explosive eruptions and the associated ash column could cause short-and long-term water supply difficulties for Vancouver and most of the lower mainland. The catchment area for the Greater Vancouver watershed is close to the Garibaldi area. Pyroclastic fall could also have a deleterious effect on the ice fields to the east of Mount Garibaldi, causing more melting and spring flooding. This in turn could endanger water supplies from Pitt Lake as well as fisheries on the Pitt River.

Lava flowsEdit

File:Ring Creek lava flow.jpg

The hazard from lava flows would be low to moderate because the nature of the lavas would prevent them from travelling far from their source, even though the Ring Creek lava flow ends only Template:Unit km from Squamish. Magma with high to intermediate levels of silica (as in andesite, dacite or rhyolite) commonly move slowly and typically cover small areas to form steep-sided mounds called lava domes. Lava domes often grow by the extrusion of many individual flows less than Template:Unit m thick over a period of several months or years. Such flows will overlap one another and typically move less than a few meters per hour. Lava flows with high to intermediate levels of silica rarely extend more than Template:Unit km from their source; for example, Garibaldi's Template:Unit km long Ring Creek dacite lava flow.

LandslidesEdit

In the past, Garibaldi has had large debris flows. A section of the mountain collapsed into the Cheakamus River valley when the glacier Garibaldi was built on melted, creating a jagged unstable slope at the head of the Cheekye River. Repeated landslides from this steep cliff have created a huge debris fan at the mouth of the Cheekye River just north of Brackendale called the Cheekye Fan. Danger from future collapses have limited the growth of Brackendale onto the fan.

The steep northern edge of The Barrier in the Garibaldi area has partly collapsed several times, the most recent being in 1855-56. This collapse created a large boulder field below it, which gave Rubble Creek its name. Danger from future collapses prompted the provincial government to declare the area immediately below it unsafe for human habitation in 1981. This led to the evacuation of the small resort village of Garibaldi nearby, and the relocation of residents to new recreational subdivisions away from the hazard zone. Although imminent danger is unlikely, special regulations exist to warn potential danger and to minimize the risk to life and property in the event of a landslide.

MonitoringEdit

Currently Mount Garibaldi is not monitored closely enough by the Geological Survey of Canada to ascertain how active the volcano's magma system is. The existing network of seismographs has been established to monitor tectonic earthquakes and is too far away to provide a good indication of what is happening beneath the mountain. It may sense an increase in activity if the volcano becomes very restless, but this may only provide a warning for a large eruption. It might detect activity only once the volcano has started erupting.

A possible way to detect an eruption is studying Garibaldi's geological history since every volcano has its own pattern of behaviour, in terms of its eruption style, magnitude and frequency, so that its future eruption is expected to be similar to its previous eruptions.

Garibaldi Lake Volcanic FieldEdit

File:Mount Garibaldi and Garibaldi Lake from 2150 meters.jpg

Mount Garibaldi is associated with a group of small volcanoes that form the Garibaldi Lake volcanic field. An unusual volcanic structure called The Table is located between Garibaldi Lake and Mount Garibaldi. This several hundred foot high flat-topped volcano is made of layers of andesitic dacite that are arranged like a stack of more or less equal sized pancakes. The Table was formed in the early Holocene at a time when the Cordilleran ice sheet covered the region. As the volcano's lava rose it melted the part of the ice sheet above The Table's vent, creating space for the lava to move into. Repeated eruptions constructed the steep-walled stack of lava seen today.

Black Tusk is a large spire of extensively eroded dark volcanic rock that is shaped like a Walrus tusk. It is considered to be the remnant of an extinct andesitic stratovolcano which formed between about 1.3 and 1.1 million years ago.

Mount Price, west of Garibaldi Lake, 5 km south of Black Tusk, was formed in three stages of activity, dating back 1.1 million years, the latest of which produced two large lava flows from Clinker Peak during the early Holocene that ponded against the retreating continental ice sheet and formed The Barrier, containing Garibaldi Lake.

Cinder Cone stands Template:Unit m above a gap between two arms of Helmet Glacier on Garibaldi's flanks. During summer its crater is filled with a snow melt lake.
